Enteroplea lacustris, dorsoventral view; specimen from (2). |
|
|
Enteroplea lacustris, same specimen anterior part; focus plane on the mastax and gastric glands. Also visible is the single cerebral eyespot. (2) |
|
|
Enteroplea lacustris, lateral view, slightly compressed specimen. (1) |
|
|
Enteroplea lacustris; head completely retracted. The transparent integument reveals a perfect view of the pseudocoel. (1) |
|
|
Enteroplea lacustris, gastric glands with typical appendages (yellow arrows). The blue arrowheads point to the insertion points of some transversal muscle fibers. (1) |
|
|
Enteroplea lacustris, amoeboid tissue (blue arrows). (1) |
|
|
Enteroplea lacustris; as some of the filaments seem to be connected to muscle fibers, they could also be part of the nervous system (?). (1) |
|
|
Enteroplea lacustris; three aspects of the trophi (stacked images) (1) |
|
|
|
Enteroplea lacustris; 2 aspects of trophi of specimen from (2) |
|
|
|
|
|
Location (1): “Rotes Moor” nearby the city of Wesenberg/Mecklenburg-Vorpommern/Germany |
Habitat (1): “Bruch” with waterplants, together with Cephalodella gigantea. About one specimen
per ml. Conductance: 85µS, pH: 6.5. |
Date (1):collected 14.7.2015, images: 22.7.2015 |
Images of sample (1) courtesy of Richard Scholz. |
|
|
|
|
Location (2): Fondotoce, Verbania, Piemont, Italy; pond |
|
|
Habitat (2): periphyton (click to enlarge >>>>) |
|
Date (2): 08.10.2021 |
|
|
|
|
|
|
|
|
|
