Adineta vaga var. rhomboidea Berzins 1950
Adineta vaga var. rhomboidea, dorsoventral view. The arrows point to the characteristic rhomboidal elevation on the first foot segment. In contrast to the descriptions of Berzins the light refracting bodies in the neck segment are not visible. (1)

Adineta vaga var. rhomboidea, dorsal view. This morphotype is characterised by some longitudinal folds of the dorsal integument; the central ones (arrowheads) are the most prominent.

Adineta vaga var. rhomboidea, dorsoventral view. Focal plane on the rostrum lamella (see right image below). (1)

Adineta vaga var. rhomboidea, three images of the anterior part of the animal. Left image: dorsal view of the head region and rostrum lamella. Two cavities on the rostrum (arrows). Right image: crop of the above image: head in optical median section. There is a pore at the base of the rostrum lamella (arrow). Lower image: head of the same specimen, Obj. 100x. Similar structures have also been found in A. steineri and A. vaga major (1)

Adineta vaga var. rhomboidea; two aspects of the head with the prehensile apparatus constisting of rakes with 5 U-hooks on each side. (1)

Adineta vaga var. rhomboidea; head, lateral view, optical median section; focus plane on the dorsal antenna. (1)

Adineta vaga var. rhomboidea; in contrast to another morphotype of A. rhomboidea (2) this morphotype has a foot with long tapering spurs. No interspace between spurs (1)



Location: Speikboden (altitude 2400m), Tauferer Ahrntal, South Tirol, Italy (1);
Habitat: dry moss on rocks (Andreaea rupestris), together with A. tuberculosa, Pleuretra lineataDissotrocha scutellata (1);
Date: coll. 7.10.2014, img 18.10.2014.(1);
Identification by courtesy of Nataliia Iakovenko, University of Ostrava, Czech republic
